Striko – SU Reverse Acting Metal Rupture Disc

Applications:

Chemical & Synthetic Fuels Mining & Minerals Oil & Gas Pulp, Paper & Cellulose

Striko SU reverse acting metal rupture discs (bursting discs) are high precision safety devices for overpressure protection that are installed in a standard holder SHU or in a...

Learn More

Contact Sales Team > Call Us +27861 103 103

All Downloads

Striko – Rupture Disc Burst Indicators

Striko

Striko – Rupture Disc or Safety Valve

Striko

Striko – Pretorqued Holder for SZ – SU

Striko

Striko – Rupture Disc Enquiry Sheet

Striko

Striko – Rupture Disc Summary

Striko

Striko – Rupture Disc Brochure

Striko

Download All

About Striko – SU Reverse Acting Metal Rupture Disc

Striko SU reverse acting metal rupture discs (bursting discs) are high precision safety devices for overpressure protection that are installed in a standard holder SHU or in a pre-torqued holder SHU Pro between flanges. When the process pressure reaches the pre-defined limit, the disc opens to relieve the system keeping personal and plant safe.

Striko SU series can be used as a primary or secondary relief device and can also be used in combination with a safety valve. They are ideal for pulsating working pressures of medium to high strength.

Protect your Safety Valves

When using the Striko SU rupture disc before a safety valve, you

Can use a safety valve with standard lower cost materials in a corrosive application.
Reduce fugitive emissions past the safety valve, due to the rupture disc being leaktight.
Reduce the costs of maintenance extending the life of the safety valve
PRV Prevent fugitive emissions.
Stop viscous media from adhering to and blocking the safety valve, hindering its performance.

SU-C series is a concave domed C-scored rupture disc that fulfills the highest requirement of tightness. The SU-C is ideally suited to processes with gases, vapours and liquids with gas cushion reliability. Due to being non-fragmenting, it has the largest possible flow cross-section and is idealy suited for installing in front of a safety relief valve. They are installed in Striko SHU and SHU Pro holders.

SU-R series is a concave domed burst safety device. The bursting foil on the robust shear ring will be torn up in case of response. The SU-R protects processes with gases, vapours and liquids with gas cushion reliability. Due to its non-fragmenting design, it is ideal for installing in front of a safety valve. For pulsating operating pressures of medium to high intensity, the SU-R is the ideal pressure protection component for your system. Materials selected for the specific application, allow the use even with corrosive media of media that tends to cake on surfaces. They are installed in Striko SHU and SHU Pro holders.

Contact one of our technical specialists for a quote today or download the brochure to learn more!

Series	SU
Design	Reverse acting metal rupture disc
Features	Non-fragmenting Leak tight preventing media leaking during normal operation Ideal as single pressure relief unit or used in combination with safety valve Vacuum resistant Counter pressures up to min 1.4 times of the burst pressure are possible Testing pressure relief valves without time consuming removal High pressure change resistance Equipped with a 3D name-plate for safe detection of correct direction of installation as a standard Ideal for securing media that tends to “cake” onto surfaces
Size Range	DN 25 – 250 / 1” – 10”
Operating Range	Burst pressures – From 0.3 bar.g to 70bar.g Working ratio – 90% Burst tolerance – +-5%
Temperatures	-200° to 480°C
Disc Materials	Stainless steel, nickel, tantalum, inconel or hastelloy,
Options & Accessories	Burst indicator or sensor
Applications	For applications where you need a simple and easy to install pressure relief safety device to protect your pressure vessel, tank or pipeline from overpressure or potentially damaging vacuum conditions. When you wish to protect your safety valve extending its lifespan.
