Striko – Rupture Disc & Safety Valve Combination

Learn More

About Striko – Rupture Disc & Safety Valve Combination

Safety valves are protected when using Striko SZ-X, SU-R or SU-C rupture discs in front of them. With this combination, you prevent fugitive emissions, stop viscous process media reaching the safety valve and thereby protect them from being blocked as well as extend the lifespan of the valves reducing overall maintenance costs.

SZ-X series is a convex domed cross-scored rupture disc that fulfills the highest requirement of tightness. The SZ-X is ideally suited for processes with medium to high pressures as well as volatile media where it protects your process reliably. Due to its non-fragmenting bursting, it can be easily installed in combination with a safety valve. It’s “Fail-Safe” design ensures that should it be installed incorrectly, it will fail at or below the specified burst pressure.

SU-C series is a concave domed C-scored rupture disc that fulfills the highest requirement of tightness. The SU-C is ideally suited to processes with gases, vapours and liquids with gas cushion reliability. Due to being non-fragmenting, it has the largest possible flow cross-section and is ideally suited for installing in front of a safety relief valve. They are installed in Striko SHU and SHU Pro holders.

SU-R series is a concave domed burst safety device. The bursting foil on the robust shear ring will be torn up in case of response. The SU-R protects processes with gases, vapours and liquids with gas cushion reliability. Due to its non-fragmenting design, it is ideal for installing in front of a safety valve. For pulsating operating pressures of medium to high intensity, the SU-R is the ideal pressure protection component for your system. Materials selected for the specific application, allow the use even with corrosive media of media that tends to cake on surfaces. They are installed in Striko SHU and SHU Pro holders.

Contact one of our technical specialists for a quote today or download the brochure to learn more!

Series	SZ-X / SU-C / SU-R
Design	Forward acting & reverse acting rupture discs
Features	Prevents leaks to the environment Protects safety valves from blockage and media Enables lower cost materials to be used Reduced maintenance costs and time Inline safety valve testing (SU-C/SU-R)
Size Range	DN 15 – 250 / 1/2” – 10”
Operating Range	Please refer to SZ-X rupture disc Please refer to SU-C & SU-R rupture discs
Temperatures	-200° to 480°C
Disc Materials	Stainless steel, nickel, tantalum, inconel or hastelloy,
Options & Accessories	Burst indicator or sensor
Applications	When you need to protect your safety valves from aggressive or caking media and wish to extend the time between required maintenance and use lower costs materials for the safety valve body
